Vacuum Lifter Pro

Vacuum Lifter Pro - AVLP1-250P

General

The Vacuum Lifter Pro is a reliable tool for lifting and tilting stone slabs such as granite, marble, and other heavy materials. Powered by compressed air, it allows smooth 0°–90° tilting, making slab handling safer and more efficient.

Features

Pneumatic Tilting – Smooth, precise 0°–90° vertical/horizontal tilting.

Vacuum Tank – Maintains suction during sudden power loss for added safety.

Alarm System – Visual and audio alerts when vacuum pressure is low, powered by a rechargeable 12V battery.

Slide Valve Control – Simple ON/OFF operation for quick attachment and release.

Dual Operation Modes –

Audio Alarm Mode: Buzzer alerts when vacuum drops below 64 kPa.
Energy Saver Mode: Automatically starts/stops the pump to maintain pressure and save air.

Adjustable Handles – Extend from 76.2 mm (3") to 106.68 mm (4.2") for better ergonomics and comfort.

Robust Construction – Durable design suitable for heavy-duty use.

Specifications

AVLP1-250P	Metric
Number of pads	1
Pad size	500 x 300 mm
Working load limit – Vertical	125 kg
Working load limit – Horizontal	250 kg
Net weight	48 kg
Gross weight	78 kg
Packaging dimensions	L.1070 x W.390 x H.980 mm

BATTERY INFORMATION – ALARM SYSTEM	Details
battery code	GBA 12V 2.0Ah Bosch
Battery type	Lithium-ION
Voltage	12V
Capacity	4.0Ah
Quantity	1
Continuous operation time (pressure saving mode)	2 hours
Working time (pressure saving mode)	6 hours
Continuous operation time (audio alarm only)	120 hours
Working time (audio alarm only)	360 hours
