AVGLP Vacuum Glass Lifters - AVGLP4-400
General
The Aardwolf AVGLP Vacuum Glass Lifters are pneumatic-powered lifting solutions designed for handling large glass and porcelain panels in construction, manufacturing, and installation environments. Built to work with both smooth and lightly textured surfaces, these lifters allow precise and secure vertical-horizontal tilting up to 90°, making them ideal for positioning panels during fabrication or installation.
The AVGLP range offers multiple models with varying pad configurations and lifting capacities—accommodating everything from smaller, compact panels to oversized sheets. Each unit features a backup vacuum tank to maintain a secure hold during unexpected power loss, while an integrated 12V battery powers the visual and audio safety alarms to enhance operator safety.
Features
- Pneumatic vertical-horizontal tilting from 0° to 90° for flexible panel positioning
- Manual or pneumatic rotation options, depending on model
- Automatic vacuum pumping to maintain suction in case of vacuum loss
- Backup 12V battery to power visual and audio safety alarms
- Quick ON/OFF slide valve for fast attachment and release of materials
- Multiple suction pad configurations to accommodate different panel sizes and weights
- Heavy-duty steel construction for durability in industrial use
- Suitable for glass, porcelain, and other smooth or lightly textured sheet materials
Specifications
AVGLP4-40 | Metric |
| Number of pads | 4 |
| Pad diameter | Seal to seal: 280 mm |
| Working load limit | Vertical: 200 kg Horizontal: 400 kg |
| Net weight | 79 kg |
| Packaging dimensions | L.1480xW.380xH.960 mm |
- Battery information for the alarm system
| Power supply | 3.7V LiPo battery |
| Battery capacity | 2000 mAh x 1 |
| Standby time | 720 hours |
| Charging cycle | 1000 times |
| Charging time | 2 hours |
| Non-stop working time | 7 hours |
| 6-month warranty | - |
- Compressed air requirement
| Air consumption | 180 liters/minute |
| Supply air pressure | 5 bars (72 psi) |
